MODGLUE 201
Automatic Box Gluing Machine
Modglue 201 is a fully automatic machine that glues f 201 american boxes or similar boxes with hotmelt glue.
Faster and safer than conventional method
The MODGLUE 201 model uses hotmelt glue for fast and strong gluing without the use of staples for f201 American boxes or similar boxes. The glue tank is temperature controlled and automatic weekly heating programme can be made according to working hours.
Bidirectional working system
The MODCGLUE 201 can either pick up the glued boxes loaded by the operator from the same direction, or it can feed the glued boxes continuously from the rear of the machine by means of a continuous infeed.The operation from both directions, the feed daughter, the glue spray length and the offset settings are made via the touch screen.
Technical specifications
Corrugated cardboard to be used thickness 3-8 mm
Box Width : 140-900 mm
Box Length : 180-940 mm
Box Height:140- unlimited mm
Number of box gluing : 5-12 boxes (depends on box size and operator)
Consumption of hotmelt glue used:
2.5 g/metre with 0.35mm nozzle
3.4 g/metre with 0.40mm injector nozzle
Machine overal size: 2128*1494*1523(h)mm
Ask us what you will do with your MODGLUE 201.
Just get in touch with us for solutions.
